Mesin UV 3D NT 720C
Mesin UV 3D NT 720C adalah printer UV 3D yang dirancang untuk menghasilkan cetakan dengan efek emboss, tekstur, dan lapisan 3D dengan detail tinggi. Mesin ini menggunakan printhead Epson i3200-U1HD dan mendukung tinta CMYK + White + Varnish untuk menghasilkan warna tajam serta efek visual yang lebih berdimensi.
* Ongkos kirim GRATIS untuk pembelian mesin digital printing wilayah Jabodetabek
*Diluar Jabodetabek Chat Admin Untuk info Gratis Ongkir
*Harga sewaktu-waktu dapat berubah mengikuti kurs dollar
*Harga sudah termasuk pajak
Pengaplikasian:
Jersey
Sticker UV
Texture Pad
3D Patchs
Trusted Certification by
Teknologi Brand Alpha
• Advanced Technology
VSOT Technology
Variable Drop Size Control for Smooth Color Transitions
600 dpi Resolution
MEMS technology with compact nozzle arrangement
Multi-Layer Curing Control
Ensures Defined 3D Structure, Enables precise layer stacking and controlled curing times for sharp edges and uniform height in raised prints
Specifications
| Name | Alpha NT 720C 3D UV 3D Label Printer |
| Model | NT- 720C 3D |
| Printing Width | <300mm |
| Printhead | Epson i3200 – U1HD*1pcs |
| Printing Speed | 8Pass 0.2-0.6m² /h 12Pass 0.1-0.4m² /h |
| Printing Resolution | 8Pass 720*2400dpi 12Pass:720*3600dpi |
| Ink Configuration | CMYK+White+Varnish |
| Applicable media | 3D Film |
| Ink Type | UV Ink |
| RIP Sofware | Maintop/PP/RIIN/Devstudio |
| Ink Supply System | 500ml ink bottle + white ink circulation + stirring |
| Operating System | Win7/Win10/Win11 |
| Ink Drying | Air Cooled UV Lamp Curing |
| Platform Suction | Adjustable |
| Print Interface | Network Interface |
| Printing Platform Lighting | LED Lighting |
| Temperature/Humadiry | Temperature: 15-30°C, Humidity: 35-65% |
| Power | 220V 4.3A 800W+150W |
| Size & Weight | Machine: 1197*905*1122 N.W 114kg+12.5kg Package: 1100*1050*720mm G.W 164kg |
